DS18 6 Channel Amplifier with Flush Mount Acrylic Cover Digital Dream

Enhance your car audio system with DS18’s FX6!

Designed and manufactured for professional car audio applications, this amplifier delivers exceptional power and high-quality sound while maintaining a small footprint for easy installation.

What sets the FX Series apart is its versatile installation options. Unlike ordinary amplifiers, these amplifiers come equipped with a surface mount adapter, allowing for both flush and surface installation. This feature provides flexibility in positioning the amplifier, making it perfect for custom car audio builds. Plus, this frame has Digital LED's controlled by a Built-In Digital Light Module!

Let's talk power! DS18’s FX6 delivers an impressive MAX power of 4500W. With RMS power outputs of 6 x 180W at 4 ohms, 6 x 250W at 2 ohms, and 3 x 500W at 4 ohms bridge, you can expect nothing less than thunderous sound quality.

In addition to its impressive power capabilities, this amplifier also offers a wide range of audio features. With a frequency response of 20Hz-20KHz, a signal-to-noise ratio of 80dB, and a damping factor of 80, you can enjoy a full spectrum of sound with exceptional clarity. The selectable X-Over feature allows you to customize your audio experience, while the bass boost range and frequency allow you to fine-tune your system to your liking.

Upgrade your car audio system with DS18’s FX6 and experience unmatched power, versatility, and sound quality!

*The FX Series adapters are not designed to be water-resistant. Please exercise caution to prevent water contact with the RGB LEDs, as exposure may result in a short circuit*

SPECS

Total Watts (Peak) 4500W
RMS Power @ 4 ohm 6 x 180W
RMS Power @ 2 ohm 6 x 250W
RMS Power @ 4 ohm Bridge 3 x 500W

AUDIO

Frequency Response 20Hz-20KHZ
Signal to Noise Ratio 80dB
Efficiency @ 4ohm 79%
Damping Factor 80
Input Impedance 28Kohms
Channel Separation 60dB
Total Harmonic Distortion (THD) 0.19%
Low Level Input Range 0.3-6V
Selectable X-Over LPF/HPF/FULL
X-Over Filter Range 40Hz-2KHz
Bass Boost Range 0~12dB
Bass Boost Frequency 50Hz

FEATURES

Amplifier Class Digital (D)
Amplifier Type Stereo Full Range
Number of Channels 6
Minimum Impedance 2 Ohm Stereo / 4 Ohm Bridge
Led Indicator Power / Protect / Clip
Power Input Terminal Size 4 Ga
Fuse Size 120A (External)
Thermal Protection Yes
Over-Load Protection Yes
DC Output Protection Yes
Short Circuit Output Protection Yes
Voltage Input Protection Yes (8.5-16.8V)
Clipping Protection Yes
Body Color / Finish
Black Aluminum

EXTRA FEATURES

Input Channel Selectable Yes (2/4/8 Channels)
Remote Level Control with Clip Indicator and Metal Case No
RCA Low Level Output No
Tiffany RCA Connector Yes
Very High Efficiency Digital Circuit Design Yes
PCB with Anti-Corrosion Protection Coating Yes
Surface Mount Component Technology Yes
Quality Control Verification using Audio Precision Instruments Yes
Surface Mounting with Digital Chasing LED Adapter Yes (Included)
Waterproof Rating IPX5 (Flush Mounting)

MEASUREMENT

Body Length 14.25" / 362mm
Body Width 4.7" / 120mm
Overall Height 1.85" / 47mm
Heatsink Length 16" / 406mm
Heatsink Width 7.2" / 182mm
Mounting Hole 14.5"x5.8" / 370x147mm
Mounting Depth 1.5" / 39mm
Gross Single Unit Weight 3.2Kg
